GKlab
Synergistic -> 1 -> GKlab v1.6.0 2001/08/19

Converts RGB color image to L*a*b* color image, and vise versa.

All of SIC process are executed on L*a*b* color space, so first and last processing have to be executed by GKlab. a converted L*a*b* color image file have L* data in a R-channel, a* data in a G-channel, b* data in a B-channel. That why, a converted L*a*b* color image looks pinkish.

L*a*b* color space is similar to the color space that human visual system feels. The values of L*a*b* are as almost same as photoshop's L*a*b*, so you can use L*a*b* image created by Photoshop.

Target files and the way to apply
L*a*b* color images or RGB color images

On the target image, click a mouse and select this plugin. Then, the parameter window will appear.
History of processes
Not recorded
Parameter
p1:Mode convert(mode)
p1= RGB to L*a*b*
p1= L*a*b* to RGB
Example 1
p1=RGB to L*a*b* [OK]


RGB image

-->
L*a*b* image
Example 2
p1=L*a*b* to RGB [OK]

L*a*b* image

-->
RGB image
